Stomatopods: amazing eyes

The more I learn about stomatopods (also known as “mantis shrimps”), the more fascinated I become with these true marvels of evolution. From the image data we have processed so far from the CONCORDE fall and spring field campaigns, it is pretty clear that stomatopod larvae were quite abundant in the nearshore waters of the northern Gulf of Mexico. As you can see from the images below, they are really cool looking animals – even Hollywood took notice, as stomatopods served as the inspiration behind the alien queen in the movie “Alien.”

Stomatopod larvae imaged in the northern Gulf of Mexico on October 30, 2015

Stomatopod larvae imaged in the northern Gulf of Mexico on October 30, 2015

The first thing you notice when you see the images of the larvae are those giant stalked eyes protruding from their heads. The eyes, which appear to be well developed in the larvae, are one of the most remarkable adaptations of the adult stomatopod. Unlike mammals and cephalopods, which have a camera like eye (single lens projecting an image onto a retina), stomatopods have a highly specialized compound eye, and each eye often moves independently from the other. They also have 12 visual pigments, giving them a huge range of detectable wavelengths, from infra-red to ultraviolet – much more than other invertebrates (Land & Nilsson 2012). In comaprison, humans only have three visual pigments (red, green, and blue), and the stomatopods can even detect different types of polarized light. Have you ever heard of circular polarized light? Well, they can see that too! The males have certain parts of the body can reflect circular polarized light in both right and left hand directions. The band across each eye has 4 rows of ommatidia that can see in color, and two rows (one on each end) detect polarized light (Chiou et al. 2008).

Image source: http://www.abc.net.au/catalyst/stories/3280489.htm

Image source: http://www.abc.net.au/catalyst/stories/3280489.htm Also, check out the interview with Dr. Justin Marshall who has been studying mantis shrimps for almost 20 years

Another impressive thing about stomatopods is their method of capturing prey. Different species of stomatopods use one of two different attack methods: smashing and spearing. You can tell what method it uses based on the morphology of the stomatopod appendages. The smashers have clubbed appendages that they flick outwards to smash their prey, and the spearers have pointy appendages that they can use to puncture their prey. The force created by these attacks is extremely powerful for their size. In fact, the movement of the appendages is so quick that it generates a large cavitation bubble. The phenomenon of cavitation happens when something in the water moves so fast that an empty space is created that the water cannot fill quickly enough. When a boat propeller rotates at a fast rate, it generates tiny cavitation bubbles. It is quite rare for an animal as small as the stomatopod to generate enough force to cause cavitation.

References:

Chiou T-H, Kleinlogel S, Cronin T, Caldwell R, Loeffler B, Siddiqi A, Goldizen A, Marshall J (2008) Circular polarization vision in a stomatopod crustacean. Current Biology 18:429-434

Land MF and Nilsson D-E (2012) Animal Eyes (2nd ed.) Oxford University Press
